As is known to all, the central bank recently issued the "Bar Code Payment Service Specification (Trial)" document, which limits the payment of QR code, barcode, etc., and the scanning static barcode payment date cannot exceed 500 yuan. The relevant regulations are from April 2018. It will be implemented on the 1st. That is to say, after the implementation of the 4.1 new regulations, the static QR code may be gradually replaced by other forms of products. Many people expressed concern about this. To this end, China pos machine network Xiaobian conducts research on various types of bar code payment products available on the market, and comprehensively analyzes product forms, usage scenarios, functional characteristics, prices, etc. for objective reference, which is convenient for everyone to choose. Suitable product. At the same time, you are welcome to participate in the end of the questionnaire, choose your best product!
First, dynamic code guest display
Typical representative product: Liandi QM10
Liandi QM10 is a simple dynamic code guest display device with small and stylish design, equipped with 1.8-inch color LCD monitor for dynamic QR code, optional Bluetooth communication, 3.7V/250mAh lithium battery, endurance Strong. Through China UnionPay dynamic two-dimensional code production equipment testing and certification, compared to static code equipment, security is significantly improved. The only fly in the ointment is that you need to use three custom shortcut keys to realize the switching display of two-dimensional code payment such as UnionPay, WeChat, Alipay, that is, by manual intervention, the static code is replaced by semi-dynamic code, in actual use. The process may affect the experience.
Dynamic code guest display does not need to cooperate with other peripherals to complete the barcode payment acceptance independently. At the same time, the price of 50-100 yuan is also very close to the people. As a lightweight display product, it is one of the preferred product types for small and medium-sized businesses.
Second, dynamic code equipment (display code + scan code)
Typical representative product: Yirui RC661
This refers to the narrow dynamic code device, that is, the device that only supports dynamic code payment, and the scan code box is one of its representative products. Taking Yirui RC661 as an example, it not only supports WeChat, Alipay, Meituan, UnionPay and Silver contact payment codes, invoice QR codes and other bar codes, but also provides marketing, data analysis, remote management and other expansion functions. The operation background has expanded and supplemented the merchant's original cash register system. However, such products need to be connected to a device or system with a cash register capability for normal use. For those businesses that do not have this condition, the cost of input can be imagined regardless of software or hardware.
In addition to scanning code boxes, equipment manufacturers have developed a wide range of dynamic code products based on their own experience and technical strength. Not only that, but they also vary greatly in function, so the price ranges from a few hundred to a thousand dollars. At present, the general dynamic code devices mainly have the following two development trends: dynamic function + streamlined function + NFC device and multi-function smart device.
Third, dynamic code + NFC equipment
Although NFC has always been in the shadow of bar code payment technology, with the continuous formation of the account-based payment consumption environment and the unremitting efforts of all parties, its characteristics of safety and comfort are still favored by the industry. As a result, most vendors have introduced NFC-enabled bar code payment products after gaining insight into this trend.
Note: There are a number of devices that list NFC functions as an option. Here, for ease of analysis, separate lists are used to distinguish them.
Desk type
Typical representative products: New World ME62, Liandi QM30
The payment counter card ME62 produced in the New World is a typical representative, with the host and guest double display, the main display is used to display the dynamic code, the customer display is used to display the amount, and the all-digital physical button is equipped to input the amount. At the same time, the built-in 13.56MHz non-contact IC card reader is used to support the payment of the card flash payment. In addition, this product has flexible communication, supports optional GPRS or WIFI communication, and specially adds voice broadcast function to broadcast transaction information. The product design is obviously more humanized than the previous types of barcode payment acceptance equipment. The experience has also improved.
This type of product controls the cost through the streamlined function, and has a good performance-price performance, the price is basically around 100-200 yuan.
2. Fixed
Typical representative product: Shanghai Shimai QR200
Shanghai Shimai QR200 is a product that can simultaneously display and scan code. It supports WeChat, Alipay, Baidu Wallet, Jingdong Wallet, UnionPay and Silver Contact Payment Code and other types of aggregate code. Although the shape is similar to the scan code box, the actual form is more inclined to the traditional POS machine, built-in embedded system, and equipped with screen, physical buttons, camera. Therefore, barcode payment acceptance can be completed without connecting a device or system with cash register capability (of course, some products also support peripherals).
This type of product is more diverse in terms of functions and access methods, and the price of 200-400 yuan is also within the acceptable range of the merchant.
In addition, it is worth mentioning that the fixed product has been modified to be used as a hanging product. Due to the special application scenarios of hanging products (used in government and public utilities), this is not specifically discussed here.
3. Portable
Typical representative products: MAYA Maya, Shanghai Shimai QR100, Liandi QM50
MAYA Maya, as an earmarked bar code payment special device, has a good sales and reputation. In addition to professional scanning code and display capabilities, it also supports UnionPay cloud flash payment and various PAY payments based on NFC technology. In order to optimize the payment experience, the special added voice announcement function is also a major feature. In addition, the unique and separate design not only supports the fixed point acceptance, but also further expands the application in the mobile scene according to actual business needs.
Also as a portable product, Shanghai Shimai QR100 has a larger gap with MAYA Maya in appearance, more similar to the scanning code gun, but the functions are basically the same.
The price of portable products is generally between 300-500 yuan, and the popularity is very high due to the wide range of application scenarios.
Fourth, multi-functional smart device
Typical representative products: Liandi APOS A8, Huiyin K2, Shangmi V1, Wang MI
Although there are some similarities in terms of functions, the biggest difference between multi-functional smart devices and other products is the system. Due to the adoption of more sophisticated intelligent systems (mostly Android systems), it has been comprehensively improved in terms of computing power, system integration, and scalability.
As the most comprehensive intelligent device, Smart POS is outstanding in all aspects. Take Liandi APOS A8 as an example, integrated integrated magnetic stripe card, IC card, thermal printing, photo, 1D/2D barcode scanning, WIFI, Bluetooth and other functional modules, fully support bank card, NFC, sound wave, scan code, etc. A payment method that satisfies the functions of many mobile Internet functions such as group purchase and take-out, mobile cash register, and member marketing, and expands the value-added application service of the POS terminal. In addition, the Qualcomm 4G full Netcom platform solution, the product performance is strong, not only supports all 4G, 3G, 2G communication standards of the three major operators, but also supports the process running Android5.X operating system version, with good system experience and communication compatibility. Sex.
In addition to smart pos, there are many smart business devices developed based on bar code payment. The following is a brief discussion of the differences.
Shanghai Huiyin K2, compared to the smart POS, removed the bank card acceptance capability and retained a higher configuration, the main price.
Shangmi V1, compared with smart POS, removes bank card, non-contact card, and NFC acceptance capabilities, and focuses on strengthening bar code payment capabilities and related experiences.
Wang MI, compared to the smart POS removed the printing module, the shape tends to the smart phone, small handheld work terminal.
While the price of a versatile smart device is generally higher than $500, the features and expandable application scenarios are imaginative.
In addition to the above products, scanners are the most widely used bar code payment acceptance devices on the market, often appearing in supermarkets, tobacco monopoly, medicine and warehouses. However, similar to the scan code box, it needs to be used with other peripherals.
The above is a small series of materials for different types of bar code payment acceptance equipment, and I hope to have reference value for friends who purchase equipment in the future. If you have a new opinion on bar code payment products, or if you want more products in the market that meet your needs, please take a few minutes to carefully fill out the survey questionnaire we designed for you and pay for your bar code payment products. Understanding and insight tell us! Questionnaire link: https://wj.qq.com/s/1866650/541f
